Hyundai Santa Cruz: Maintenance / Engine Compartment

1. Engine coolant reservoir
2. Brake fluid reservoir
3. Air cleaner
4. Engine oil dipstick
5. Engine oil filler cap (2.5 T-GDI’s filler cap is under the engine cover)
6. Windshield washer fluid reservoir
7. Fuse box
8. Battery

    Maintenance
    ...

    Maintenance Services
    You should exercise the utmost care to prevent damage to your vehicle and injury to yourself whenever performing any maintenance or inspection procedures. We recommend you have your vehicle maint ...
